Мідний L2+ комутатор Raisecom ISCOM 2648G-4GE-AC (знято з виробництва)

Керований L2+ комутатор доступу, 48 портів 10/100/1000 Base-T и 4 комбо-порти (10/100/1000 Base-T/SFP) Код:ISCOM 2648G-4GE-AC Категорія:Телекомунікаційне обладнання

Комутатор ISCOM2648G-4C є гігабітним комутатором доступу в безвентиляторному виконанні на базі ОС Linux.

Оснащений 48xGE мідними клієнтськими інтерфейсами (RJ45) та 4 комбо-портами (10/100/1000 Base-T/SFP) аплінками.

Пристрій має широкий функціонал, високу пропускну здатність, надійність і повною мірою задовольняє вимоги будь-якого рівня складності сучасних мереж доступу. Приємною і корисною особливістю є підтримка механізму Dying Gasp.

Особливості і функціонал
MAC address table
  • – 16K MAC addresses;
  • – Automatic learning and aging of MAC addresses and static MAC address;
  • – Static, dynamic, and blackhole MAC address entries;
  • – MAC address limit based on interface or VLAN;
  • – Managing MAC address flapping;
VLAN
  • – 4k VLANs;
  • – MAC/protocol/IP subnet/interface-based VLAN;
  • – Basic QinQ, Selective QinQ;
  • – VLAN mapping;
  • – Private VLAN;
  • – Voice VLAN;GVRP;
Buffer Size
  • – 1.5M;
Jumbo Frame
  • – 12K
Ring Network Protection
  • – ERPS (G.8032);
  • – STP/RSTP/MSTP/MRSTP;
  • – BPDU protection and root protection;
  • – Loop detection
Відмовостійкість
  • – LACP, MC-LAG;
  • – Interface Backup;
  • – Стекирование ISF;
  • – 2 образа ПО в системе (основной и резервный);
  • – 2 конфигурационных файла в системе (основной и резервный);
IP Routing
  • – IPv4 and IPv6 static routes;
Multicast
  • – IGMPv1/v2/v3 Snooping and immediate leave;
  • – Interface/user-based immediate leave;
  • – Static multicast group;
  • – IGMP MVR;
  • – MLD v1/v2 Snooping;
  • – IGMP Proxy;
  • – IGMP Filter;
DHCP
  • – DHCP Client (Normal and Zero Mode);
  • – DHCP Snooping;
  • – DHCP Relay;
  • – DHCP Server and Option43;
  • – DHCP Snooping Option61/82 and DHCP Relay Option 82;
Зеркалирование (Mirroring)
  • – Traffic mirroring;
  • – Local and remote port mirroring;
QoS/ACL
  • – Rate limiting in the ingress/egress interface direction;
  • – 8 queues for each interface;
  • – SP, WRR, DRR, SP+WRR, and SP+DRR;
  • – Packet redirection;
  • – 802.1p and DSCP priority remarking for packets;
  • – Interface-based traffic monitoring and dual-rate three-color CAR;
  • – L2–L4 packet filtering based on source MAC address and destination MAC address;
  • – Packet filtering based on source IP address, destination IP address, TCP/UDP source/destination, interface ID, protocol, and VLAN;
  • – Hierarchy-CAR;
Безпека
  • – Hierarchical user management and password protection;
  • – 802.1x authentication based on interface and MAC address;
  • – CPU protection and anti-ARP attack;
  • – Group binding of IP address, MAC address, interface, and VLAN;
  • – Blackhole MAC address;
  • – MAC address limit;
  • – AAA, RADIUS, and TACACS+;
  • – Interface isolation;
  • – Port security MAC;
  • – SSHv2.0;
  • – SFTP;
  • – HTTPS;
  • – DHCP Snooping and DHCP server which prevents against spoofing;
  • – Dynamic ARP inspection, preventing MITM and ARP DoS;
  • – BPDU guard and root guard;
Управління і обслуговування
  • – Management through the Console interface and out-of-band interface;
  • – SNMPv1/v2c/v3 and various management modes, such as CLI, Web, Telnet, and SSHv2.0;
  • – Raisecom NView NNM system;
  • – RMON;
  • – LLDP/LLDP-MED;
  • – Syslog and hierarchical alarm reporting;
  • – Ping and Tracert;
  • – Dying Gasp alarm;
  • – NTP and SNTP;
  • – Cable test;
  • – Interface loopback;
  • – Auto-provisioning, which means that configurations can be automatically; downloaded and software;
  • – Interface loop detection;
  • – Optical module DDM;
  • – Link-state tracking;
  • – DLDP unidirectional link detection;


Lightning protection

  • – Interface lightning protection: 6 KV
